CENTRIFUGAL PUMPING SOLUTIONS

---

 Range Description  :

• Size : 50 to 400 mm
• Capacities : Upto 3500 m3/hr
• Head : Upto 200 m
• Speed : Upto 3000 rpm

 Options  :

Materials– CI, DI, Bronze, SS, Ni Resist  Stuffing Box– Packed Gland , Mechanical Seal  Orientation – Horizontal/Vertical  Construction– Foot/ Centre Line Mounting,

Features Bearing options, cooling options,  staggered vane and special impellers

 Features :

 1. High Efficiency  2. Low NPSHr

3. Stable Characteristics  4. Over 45 frames ensures optimum selection for all duties  5. Quick Customisation possible to ensure optimum operation.  6. High head units have double volute casings to reduce  radial thrust.

 Range Description  :

• Size : 32 to 400mm
• Capacities : Up to 2500 m3/hr
• Head : Up to 160 m
• Speed : Up to 3000 rpm

   Options :

Material – CI, DI, Bronze, SS, Ni Resist

Stuffing Box– Packed Gland, Mechanical Seal  Construction– Foot/ Centre line mounting,  Features  - Bearing options, Cooling options,  Open & semi-open impellers

 Features  :

1. Conforms to ISO 2858

2. Conforms to ISO 5199

3. High Efficiency, Low NPSHR

 4. Over 60 frames ensures optimum selection  for all duties

5. Quick customisation possible to ensure  optimum operation.

Range Description :

• Size  :  65 to 250 mm
• Capacities : Up to 1200 m3/hr
•  Head  : Up to 350 m
• Speed  :   Up to 3000 rpm

 Options  :

Materials -  CI, DI, Bronze, SS, Ni Resist

Stuffing Box  – Packed Gland, Mechanical Seal Orientation  -  Horizontal / Vertical

Construction – Foot / Centre line mounting

Features - Bearing options, Cooling options  staggered vane & special impellers.

Features  :

 1. High Efficiency  2. Both integral & external cross-over are used to ensure  Optimum performance  3. Two single /double entry impeller placed back to back  to eliminate axial thrust.  4. Head Characteristics more stable and efficiency  higher compared to single stage units.  5. Special custom-built units.
